Laser cleaning machine has the advantages of easy to control, easy automatic integration, no chemical reagents, suitable surface cleaning, high cleaning cleanliness and high accuracy, efficient and environmental protection, safe and reliable, almost no damge substrate surface, which can solve a variety of problems that cannot be solved by traditional cleaning. Including metal rust, metal particles, dust, etc., the application effects include: rust removal, paint peeling, oil removal, cultural relics repair, glue removal, decoating, decoating.
| Quantity: | |
|---|---|
SLC1000/1500/2000
ARGUS
| Technical parameters | |||
| Equipment model | Fiber laser cleaning machine | ||
| Laser power | 1000W | 1500W | 2000W |
| Laser Type | continuous | ||
| Laser wavelength | 1070nm | ||
| Cooling mode | water cooling | ||
| Cooling water type | Purified water / laser special antifreeze / alcohol + water | ||
| Working water temperature | 18-35 ºC (Reference range) | ||
| Cleaning head weight | After paragraph 1.2KG (2020) | ||
| Operating Machine Weight | 160KG | ||
| Complete power | ≤ 3000W | ||
| Scan width | 10-120mm | ||
| Operating temperature | 15ºC-55ºC | ||
| Optional options | Handheld / Automation/ Non-standard customization | ||
Comparison of the cleaning scheme
Comparison | |||||
Contrison items | Chemical cleaning | Mechanical grinding | Dry ice cleaning | Ultrasonic cleaning | Laser cleaning |
Cleaning mode |
Chemical cleaning agent | Mechanical / sandpaper, contact type | Dry ice, noncontact type | Cleaning agent, contact type | Laser, contactless |
Workpiece damage | Damage | Damage | No damage | No damage | No damage |
Cleaning efficiency |
Low level |
Low level |
Medium |
Medium | High level |
Cleaning effect | Generally, the uneven | Generally, the uneven | Excellent, uneven | Excellent, with a small clean range | Very good, high cleanliness |
Cleaning accuracy | Uncontrollable, with poor accuracy | Uncontrollable, with general accuracy | Uncontrollable, with poor accuracy | Unspecified range of cleaning | Accurate and controllable, with high precision |
Safety / Environmental protection | Severe chemical pollution | Environmental pollution | No pollution | No pollution | No pollution |
Manual operation | Complex procedures requires high requirements and protective measures | High physical strength and required safety protection measures | Simple to operate, handheld or automated | Simple to operate, but requires manual addition of consumables | Simple to operate, handheld or integrated automation |
Consumables | Chemical cleaning agent | Sandpaper, sand wheel, tartar etc | Dry ice |
Special cleaning fluid | Power power supply |
Cost input | Low first- time investment and extremely high consumables cost | High first investment and high labor cost of consumables | Medium initial investment, high consumables cost | Low initial input, moderate consumables cost | High first- time investment, no consumables, and low maintenance cost |
