Laser Perforation and Scoring Machine - Wuhan Sunic Photoelectricity Equipment Manufacture Co.,LTD

English

Laser Galvo Head Model

Laser technology enables high-precision scoring, cutting, and perforation of flexible packaging materials. Perforation helps regulate gas and moisture exchange, extending the shelf life of packaged products such as fresh produce or snacks. It also allows most retail products to be perforated for hanging display. Rapid laser perforation creates protective, round-edged holes that resist tearing, ensuring clean and damage-free cuts while supporting dynamic roll-to-roll processing. Compared to similar systems, it offers superior precision and speed efficiency, making it an ideal solution for innovative flexible packaging applications.

Applications

Cross Web Scoring – Along the moving direction of the roll (for easy-open features)
mircro perforation – For promotional items, pour spouts,Easy-open design for bottle seal packaging
small hole cutting – Breathable Packaging (for Fresh Food Preservation), Retail Packaging for Easy Hanging Display

Efficient Processing

The system allows for setting different hole sizes and can synchronize with high-speed rollers to enhance personalized production efficiency.

Argus Laser, the laser expert beside you, with 26 years of experience in laser equipment design and manufacturing, we provide more professional advice for your industrial technology improvement.

We are happy to provide you with the right laser solution for flexible packaging.

This series is designed for continuous or intermittent scoring or perforating to achieve easy opening of regular packaging, and is also suitable for resealing or zipper functionality.

MATERIALS
Plastic Films
Polyester
Polyethylene
Polypropylene
EVOH
Nylon
Laminations
Foils
PLA

CAPABILITIES
Laser Scoring

Laser Slitting
Laser Micro-Perforating

Laser Perforating

FEATURES & BENEFITS

Choosing a Laser Head Model for laser equipment has many benefits, and these are just some of them.

Customizable Equipment

Laser systems can operate as standalone units or be integrated into existing production lines

Various Materials and Thicknesses

Processes various packaging materials up to 12 mil thick

Cursor Positioning

Ensures laser processing aligns precisely with printed patterns

Output Power Control

Precisely controls laser energy based on material and requirements

Acceleration - Deceleration Control

Eliminates waste caused by material overload when processing speeds are below normal

Superior Scoring Quality

Consistent scoring depth and uniformity. Repeatable strength and tear quality

Fast Setup and Mode Changes

Adjust scoring depth, perforation size, and spacing using proprietary softwareConsistent scoring depth and uniformity. Repeatable strength and tear quality

Non-contact Processing

Eliminates inconsistencies associated with cutting tools and mechanical perforators

TECH SPECS

The technical specifications are based on baseline standards, but all laser equipment can be customized to meet your product requirements.

	Vertical	Horizontal
Lasers	1 - 8	1 - 4
Cloth	1 - 8	1 - 4
Cross Axis Beam Adjustment Rows	2 Rows (4 output heads per row maximum)	1 Row (4 output heads per row maximum)
Laser Power	55/70/100 watts
Laser Source	Coherent CO2metal R.F. Laser source
Laser Wavelength	10.6 µm
Laser Frequency	1kHz~25kHz
Galvo Head	High speed galvo scanner
Idle marking speed	3000mm/s
Flim perforation speed	50-280 meters/min (according to the material, laser power and processing design)
Repetition Precision	0.01mm
High precision sensor	Japanese RGB Sensor Eye Mark Reader ( Response time 200us)
Including	Emulated encoder,Customized mounting structure, Computer with software, Exhausting Fans, Air Pump
Control System	JCZ/BSL
Power Supply	110V~220V/50Hz~60Hz
Cooling Way	Air/water Cooling
Multi-head	Avaible according to the request

**The above data may change due to product upgrades. For specific details, please contact us.
