ARGUS 3D Denim Jeans Whisker Machine Laser Engraving and Marking Machine Jeans Laser Washing Machine

The dynamic galvo co2 laser marking machine is suitable for denim jeans destroy grinding,jeans washing,logo marking etc processing. It has been widely used in clothing garment industry.
Availability:
Quantity:
  • SCM3000/SCM1400L

  • ARGUS

2.烧花机海报

Introduction

Top 1 Denim jeans laser printing,engraving,washing,whisker machine.

The SCM1400L 3D Dynamic CO2 Laser Marking Machine is specialized designed for denim Laser Marking Application, which is widely used in the jeans producing, and it is also the most popular model in the market.It is the outcomes of SUNIC Laser’s technical expertise and experience in marking and engraving denim for jeans applications exploiting proprietary laser technology to produce washing mark, whisker result on denim up to four switch table 1300×600 mm working size. This process is much more productive in comparison to other traditional technologies and other lasers, even with the maximum quality.

Machine Structure

CO2 Dynamic Laser Marking Machine SCM3000 main structures:

  • Imported laser tube

  • High speed galvo scanner

  • Sunic Laser self-developed linear 3D Dynamic Focusing System

  • Device control system

  • Self-developed Control software

  • The high precision thermostatic water cooling system.


The host machine is as follow:

Machine’s Control section is focused on the Electrical main control section. The whole machine’s optical components are focused on the optical main beam and inside the square head through the complete optical design. The integrated water chiller provides a circulation water cooling system for the machine during working. CO2 Dynamic Laser Marking Machine mainly includes the following parts:

  • Optical System

  • Water Cooling System

  • Electrical Control System

  • IPC&Marking Motion Card

  • Sunic Laser Self-developed Control Software

  • Exhausting System

Machine Details

烧花机详情页



Technical Parameter


Model

SCM3000 SCM1400L

Max working Area

1500*1500mm

switch table:1300*400mm *4

Laser power

250 watts/350watts

250 watts/350watts/500watts

Power Consumption

≤ 7kWh

≤ 7kWh

Life Span

Over 20000 hours

Over 20000 hours

Marking Speed

≤10000mm/s

≤10000mm/s

Worktable

Marble worktable

MDF/Strip/Honeycomb worktable

Laser Source

US Coherent Diamond J Series Laser Tube

US Coherent Diamond J Series Laser Tube

Laser Wavelength

10.64μm

10.64μm

Laser Frequency

20kHz~200kHz

20kHz~200kHz

Focusing method

3D dynamic focusing system

3D dynamic focusing system

System Support

Windows

Windows

Output Compatibility

Auto CAD, Photoshop, CorelDRAW etc

Auto CAD, Photoshop, CorelDRAW etc

File Formats

PLT, DXP, BMP, JPG, AI etc

PLT, DXP, BMP, JPG, AI etc


Software Character

Integrated Function of Dotting Design, Vector Drawing, Marking, Scribing and Cutting

Integrated Function of Dotting Design, Vector Drawing, Marking, Scribing and Cutting

Power Supply

110V~380V/50Hz~60Hz

110V~380V/50Hz~60Hz

Cooling Way

Circulation of Water Cooling

Circulation of Water Cooling


Features

The denim processed by Laser Engraving display the excellent features of quick producing speed, no need washing process, Environment friendly, easy customized design, and permanent result.Technical Parameters


Packaging


Size:1000(L)*800(W)*600(D)

Gross Weight:400KG

Packaging Details:Standard Crate for export. Whole machine will be covered with film before packing.
